5. PARAMETERS

5 - 15

No.

Symbol

Name

Initial

value

Unit

Operation

mode

Standard

PT68

For manufacturer setting

0102h

PT69

ZSTH

Home position shift distance (extension parameter)

[µm]/

-4

[inch]/

-3

[degree]/

[pulse]

PT70

For manufacturer setting

0000h

PT71

DCTH

Travel distance after proximity dog (extension parameter)

STM

[µm]/

(STM-4)

[inch]/

-3

[degree]/

[pulse]

PT72

ECMXL

Synchronous encoder electronic gear - Numerator

0000h

PT73

ECMXH

0000h

PT74

ECDVL

Synchronous encoder electronic gear - Denominator

0000h

PT75

ECDVH

0000h

PT76

For manufacturer setting

0000h

PT77

0000h

PT78

0000h

PT79

0000h

PT80

0000h
