11. OPTIONS AND PERIPHERAL EQUIPMENT
11 - 14
11.3 Setup software (MR Configurator2
TM
)
Setup software (MR Configurator2
TM
) (LEC-MRC2
□
) uses the communication function of the driver to
perform parameter setting changes, graph display, test operation, etc. on a personal computer.
When setup software (MR Configurator2
TM
) is used, the selection of the model of LECSN
□
-T
□
is
needed. Please select 'MR-J4-TM' by "Model" - "New" - "Project".
11.3.1 Specifications
Item
Description
Project
Create/read/save/delete project, system setting, and print
Parameter
Parameter setting
Monitor
Display all, I/O monitor, graph, and ABS data display
Diagnosis
Alarm display, alarm onset data, drive recorder, no motor rotation, system configuration, life
diagnosis, and machine diagnosis
Test operation
JOG operation (Note 1), positioning operation, motor-less operation (Note), DO forced output,
and program operation
Adjustment
One-touch tuning, tuning, and machine analyzer
Others
Servo assistant, parameter setting range update, machine unit conversion setting, and help
display
