17．HOW TO USE INDEXER
17 HOW TO USE INDEXER
POINT
In the absolute position detection system, rotating the shaft one revolution or
more during power-off may erase the home position. Therefore, do not rotate the
shaft one revolution or more during power-off. When the home position is
erased, [AL. 90 Home position return incomplete warning] will occur. Then,
execute the home position return again.
For the home position return, refer to chapter 18,19,20.
There are the following restrictions on [Pr. PA06 Number of gear teeth on
machine side] and the servo motor speed (N).
When CMX ≤ 2000, N < 3076.7 r/min
When CMX > 2000, N < (3276.7 - CMX)/10 r/min
When the servo motor is operated at a servo motor speed higher than the limit
value, [AL. E3 Absolute position counter warning] will occur.
See the following table for the No. of each object mentioned in this chapter.
Object
No.
EtherCAT
PROFINET
Modes of operation
Index: 6060h
PNU: 24672, Sub: 0
Controlword
Index: 6040h
PNU: 24640, Sub: 0
Statusword
Index: 6041h
PNU: 24641, Sub: 0
Profile velocity
Index: 6081h
PNU: 24705, Sub: 0
Profile acceleration
Index: 6083h
PNU: 24707, Sub: 0
Profile deceleration
Index: 6084h
PNU: 24708, Sub: 0
Positive torque limit
value
Index: 60E0h
PNU: 24800, Sub: 0
Negative torque limit
value
Index: 60E1h
PNU: 24801, Sub: 0
Target point table
Index: 2D60h
PNU: 11616, Sub: 0
Status DO 1
Index: 2D11h
PNU: 11537, Sub: 0
Status DO 5
Index: 2D15h
PNU: 11541, Sub: 0
Point actual value
Index: 2D69h
PNU: 11625, Sub: 0
Torque limit value2
Index: 2D6Bh
PNU: 11627, Sub: 0
