19．EtherNet/IP COMMUNICATION
19.7.2 Supported object library list
Group
Name
Class ID
Instance ID
General Objects
Identity Object
01h
Store parameters
64h
1010h
Communication Setting Objects
Message Router Object
02h
Connection Manager Object
06h
Device Level Ring(DLR) Object
47h
QoS Object
48h
TCP/IP Interface Object
F5h
Ethernet Link Object
F6h
Assembly Objects
Assembly Object
04h
Parameter Objects
PA_ _
64h
2001h to 2020h
PB_ _
2081h to 20C0h
PC_ _
2101h to 2150h
PD_ _
2181h to 21B0h
PE_ _
2201h to 2240h
PF_ _
2281h to 22C0h
PL_ _
2401h to 2430h
PT_ _
2481h to 24D0h
PN_ _
2581h to 25A0h
Alarm Objects
Alarm history newest
64h
2A00h
Alarm history _
2A01h to 2A0Fh
Clear alarm history
2A40h
Current alarm
2A41h
Parameter error number
2A44h
Parameter error list
2A45h
Monitor Objects
Cumulative feedback pulses
64h
2B01h
Servo motor speed
2B02h
Droop pulses
2B03h
Cumulative command pulses
2B04h
Command pulse frequency
2B05h
Regenerative load ratio
2B08h
Effective load ratio
2B09h
Peak load ratio
2B0Ah
Instantaneous torque
2B0Bh
Within one-revolution position
2B0Ch
ABS counter
2B0Dh
Load to motor inertia ratio
2B0Eh
Bus voltage
2B0Fh
Load-side cumulative feedback pulses
2B10h
Load-side droop pulses
2B11h
Load-side encoder information 1 Z-phase counter
2B12h
Load-side encoder information 2
2B13h
Temperature of motor thermistor
2B17h
Motor-side cumu. feedback pulses (before gear)
2B18h
Electrical angle
2B19h
Motor-side/load-side position deviation
2B23h
Motor-side/load-side speed deviation
2B24h
Internal temperature of encoder
2B25h
Settling time
2B26h
Oscillation detection frequency
2B27h
Number of tough drive operations
2B28h
Unit power consumption
2B2Dh
Unit total power consumption
2B2Eh
Alarm Monitor 1 Cumulative feedback pulses
2B81h
