5.1.4 I/O setting parameters ([Pr. PD_ _ ])
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Standard
PD01
*DIA1
Input signal automatic on selection 1
0000h
PD02
For manufacturer setting
0000h
PD03
*DI1
Input device selection 1
000Ah
PD04
*DI2
Input device selection 2
000Bh
PD05
*DI3
Input device selection 3
0022h
PD06
For manufacturer setting
0000h
PD07
*DO1
Output device selection 1
0005h
PD08
*DO2
Output device selection 2
0004h
PD09
*DO3
Output device selection 3
0003h
PD10
For manufacturer setting
0000h
PD11
*DIF
Input filter setting
0004h
PD12
*DOP1
Function selection D-1
0101h
PD13
*DOP2
Function selection D-2
0000h
PD14
*DOP3
Function selection D-3
0000h
PD15
For manufacturer setting
0000h
PD16
0000h
PD17
0000h
PD18
0000h
PD19
0000h
PD20
0
PD21
0
PD22
0
PD23
0
PD24
0000h
PD25
0000h
PD26
0000h
PD27
0000h
PD28
0000h
PD29
0000h
PD30
0
PD31
0
PD32
0
PD33
0000h
PD34
0000h
PD35
0000h
PD36
0000h
PD37
*TPOP
Touch probe function selection
0000h
PD38
*TPR1
Touch probe selection 1
002Ch
PD39
For manufacturer setting
002Dh
PD40
0
PD41
0000h
PD42
0000h
PD43
0000h
PD44
0000h
PD45
0000h
PD46
0000h
PD47
0000h
PD48
0000h
