19 - 92
19EtherNet/IP COMMUNICATION
19.6.5 Parameter object
19.6.5.1 Definition of parameter objects
The parameter of the driver can be changed on the master (upper side) by writing values to the following
objects in the Explicit Message communication. However, once the power supply is shut off, the changed
setting is not held at the next startup. To hold the changed setting even after the power supply is shut-off,
save the parameter setting value to EEP-ROM using Store Parameters (Class ID: 64h, Ins ID: 1010h).
To change the setting of the parameters where the changes are reflected by cycling the power (parameters
whose symbols are preceded by **), change the value of the corresponding object and execute Store
Parameters (Class ID: 64h, Ins ID: 1010h) before cycling the power. Refer to chapter 5 of for "**" of the
parameter symbol. The following table lists the related objects.
Class
ID
Ins ID
Attr ID
Acces
s
Name
Data
Type
Description
64h
2001h
0
Get/S
et
PA01
DINT
[Pr. PA_ _] group
:
:
:
:
:
2020h
0
Get/S
et
PA32
DINT
2081h
0
Get/S
et
PB01
DINT
[Pr. PB_ _] group
:
:
:
:
:
20C0
h
0
Get/S
et
PB64
DINT
2101h
0
Get/S
et
PC01
DINT
[Pr. PC_ _] group
:
:
:
:
:
2150h
0
Get/S
et
PC80
DINT
2181h
0
Get/S
et
PD01
DINT
[Pr. PD_ _] group
:
:
:
:
:
21B0h
0
Get/S
et
PD48
DINT
2201h
0
Get/S
et
PE01
DINT
[Pr. PE_ _] group
:
:
:
:
:
2240h
0
Get/S
et
PE64
DINT
2281h
0
Get/S
et
PF01
DINT
[Pr. PF_ _] group
:
:
:
:
:
22C0
h
0
Get/S
et
PF48
DINT
2401h
0
Get/S
et
PL01
DINT
[Pr. PL_ _] group
:
:
:
:
:
2430h
0
Get/S
et
PL48
DINT
2481h
0
Get/S
et
PT01
DINT
[Pr. PT_ _] group
:
:
:
:
:
24D0
h
0
Get/S
et
PT80
DINT
2581h
0
Get/S
et
PN01
DINT
[Pr. PN_ _] group
:
:
:
:
:
25A0h
0
Get/S
et
PN32
DINT
