SMC Networks LECSN-T Series - Page 120

5. PARAMETERS
5 - 14
No.
Symbol
Name
Initial
value
Unit
Operation
mode
Standard
PT21
*LNPL
Position range output address -
0000h
10
STM
[µm]/
10
(STM-4)
[inch]/
10
-3
[degree]/
[pulse]
PT22
*LNPH
0000h
PT23
For manufacturer setting
0
PT24
0
PT25
0
PT26
*TOP2
Function selection T-2
0000h
PT27
*ODM
Indexer method - Operation mode selection
0000h
PT28
*STN
Number of stations per rotation
8
[stations]
PT29
*TOP3
Function selection T-3
0000h
PT30
For manufacturer setting
0000h
PT31
0000h
PT32
0000h
PT33
0000h
PT34
**PDEF
Point table default
0000h
PT35
*TOP5
Function selection T-5
0000h
PT36
For manufacturer setting
0000h
PT37
10
PT38
0000h
PT39
INT
Torque limit delay time
100
[ms]
PT40
*SZS
Station home position shift distance
0
[pulse]
PT41
ORP
Home position return inhibit function selection
0000h
PT42
For manufacturer setting
0
PT43
0
PT44
0000h
PT45
HMM
Home position return method
37
PT46
ESTC
Synchronous encoder filter time constant
0
[ms]
PT47
For manufacturer setting
0000h
PT48
0000h
PT49
STA
Acceleration time constant
0
[ms]
PT50
STB
Deceleration time constant
0
[ms]
PT51
STC
S-pattern acceleration/deceleration time constant
0
[ms]
PT52
For manufacturer setting
0
PT53
TQS
Torque slope
0.0
[%/s]
PT54
For manufacturer setting
0
PT55
*TOP8
Function selection T-8
0000h
PT56
HMA
Home position return acceleration time constant
0
[ms]
PT57
HMB
Home position return deceleration time constant
0
[ms]
PT58
For manufacturer setting
100.00
PT59
500.00
PT60
1000.00
PT61
200.00
PT62
0000h
PT63
0000h
PT64
0000h
PT65
PVC
Profile speed command
100.00
[r/min]
PT66
MPVC
Maximum profile speed
20000.00
[r/min]
PT67
VLMT
Speed limit
500.00
[r/min]
