20．PROFINET COMMUNICATION
The machine diagnostic status is returned. The description is as follows.
Bit
Description
0 to 3
Friction estimation status at forward rotation
0: Friction is being estimated. (normal)
1: Estimation is completed. (normal)
2: The servo motor may rotate in one direction too frequently. (warning)
3: The servo motor speed may too slow for friction estimation. (warning)
4: The change in the servo motor speed may be small for friction estimation. (warning)
5: The acceleration/deceleration time constants may be too short for friction estimation. (warning)
6: The operation time may not be enough. (warning)
When warning conditions for 2 to 6 are met at the same time, the smaller number is returned.
When an estimation is completed even though a warning has once occurred, the status changes to Estimation is
completed.
4 to 7
Friction estimation status at reverse rotation
0: Friction is being estimated. (normal)
1: Estimation is completed. (normal)
2: The servo motor may rotate in one direction too frequently. (warning)
3: The servo motor speed may too slow for friction estimation. (warning)
4: The change in the servo motor speed may be small for friction estimation. (warning)
5: The acceleration/deceleration time constants may be too short for friction estimation. (warning)
6: The operation time may not be enough. (warning)
When warning conditions for 2 to 6 are met at the same time, the smaller number is returned.
When an estimation is completed even though a warning has once occurred, the status changes to Estimation is
completed.
8 to 11
Vibration estimation status
0: During estimation
1: Estimation is completed.
12 to 15
(reserved) The value at reading is undefined.
(3) Static friction torque at forward rotation (P11297)
Static friction torque at forward rotation can be obtained. Refer to section 8.9 for details.
PNU
Sub
Access
Name
Data Type
Description
Default
11297
0
R
Static friction torque at
forward rotation
Integer16
Static friction torque at forward rotation
PNU
Sub
Range
Units
EEP-ROM
Parameter
11297
0
Refer to the text.
0.1%
Impossible
(4) Dynamic friction torque at forward rotation (at rated speed) (P11298)
Dynamic friction torque at forward rotation (at rated speed) can be obtained. Refer to section 8.9 for
details.
PNU
Sub
Access
Name
Data Type
Description
Default
11298
0
R
Dynamic friction torque at
forward rotation (at rated
speed)
Integer16
Dynamic friction torque at forward rotation
(at rated speed)
PNU
Sub
Range
Units
EEP-ROM
Parameter
11298
0
Refer to the text.
0.1%
Impossible
