Power control (PWR) RM0453
262/1450 RM0453 Rev 5
In Shutdown mode, the following features can be selected by programming individual
control bits:
• Real-time clock (RTC): this is configured by the RTCEN bit in the backup domain
control register (RCC_BDCR).
Caution: In case of V
DD
power-down, the RTC content is lost.
• External 32.768 kHz oscillator (LSE): this is configured by the LSEON bit in the backup
domain control register (RCC_BDCR)
Exit Shutdown mode
The Shutdown mode is exited according Section 6.5.4. A power-on reset occurs when
exiting from Shutdown mode. All registers (except for the ones in the backup domain) are
reset after wake-up from Shutdown.
Refer to the table below for more details on how to exit Shutdown mode.
6.5.12 Auto-wake-up from low-power mode
The RTC can be used to wake up the MCU from low-power mode without depending on an
external interrupt (auto-wake-up mode). The RTC provides a programmable time base for
waking up from Stop (0, 1 or 2) or Standby mode at regular intervals. For this purpose, the
Table 55. Shutdown mode
Shutdown mode Description
Mode entry
WFI (wait for interrupt) or WFE (wait for event) while:
– SLEEPDEEP bit is set in Cortex system control register
– No interrupt (for WFI) or event (for WFE) is pending
– LPMS = 0b1xx in PWR_CR1 and PWR_C2CR1
– WUFx bits are cleared in power status register 1 (PWR_SR1)
On return from ISR while:
– SLEEPDEEP bit is set in Cortex system control register
– SLEEPONEXT = 1
– No interrupt is pending
– LPMS = 0b1xx in PWR_CR1 and PWR_C2CR1
– Radio IRQ is cleared in the sub-GHz radio.
– WPVDF, WRFBUSY and WUFx bits are cleared in power status register 1
(PWR_SR1)
– The RTC flag corresponding to the chosen wake-up source (RTC Alarm A,
RTC Alarm B, RTC wake-up, synchronous binary counter or timestamp
flags) is cleared
– TAMP flags ITAMPxF and TAMPxF are cleared.
Mode exit WKUPx pin edge, RTC and TAMP event, external reset in
NRST pin
Wake-up latency Reset phase
