RM0453 Rev 5 223/1450
RM0453 Sub-GHz radio (SUBGHZ)
227
5.10.55 Sub-GHz radio HSE32 OSC_IN capacitor trim register
(SUBGHZ_HSEINTRIMR)
Address offset: 0x911
Reset value: 0x12
This register is retained in Sleep mode, but lost in Deep-Sleep mode.
5.10.56 Sub-GHz radio HSE32 OSC_OUT capacitor trim register
(SUBGHZ_HSEOUTTRIMR)
Address offset: 0x912
Reset value: 0x12
This register is retained in Sleep mode, but lost in Deep-Sleep mode.
76543210
Res. Res. TRIM[5:0]
rw rw rw rw rw rw
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:0 TRIM[5:0]: HSE32 XTAL mode OSC_IN load capacitor trimming
Load capacitor trimming step size ~0.47 pf.
0x00: minimum value ~11.3 pF
...
0x12 value ~20.3 pF (default)
...
0x2F: maximum capacitor value ~33.4 pF
Others: reserved
76543210
Res. Res. TRIM[5:0]
rw rw rw rw rw rw
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:0 TRIM[5:0]: HSE32 XTAL mode OSC_OUT load capacitor trimming
Load capacitor trimming step size ~0.47 pf.
0x00: minimum value ~11.3 pF
...
0x12 value ~20.3 pF (default)
...
0x2F: maximum capacitor value ~33.4 pF
Others: reserved
