Power control (PWR) RM0453
282/1450 RM0453 Rev 5
6.6.20 PWR security configuration register (PWR_SECCFGR)
Address offset: 0x08C
Reset value: 0x0000 8000
This register is not reset when exiting Standby modes.
Access: three additional APB cycles are needed to write this register versus a standard APB
write.
This register can only be accessed by a secure privileged access for read and write. Non-
secure and unprivileged accesses are ignored and return zero data. Furthermore an illegal
access event is generated.
Note: When the system is non-secure (ESE = 0), this register cannot be written and is read as 0.
6.6.21 PWR sub-GHz SPI control register (PWR_SUBGHZSPICR)
Address offset: 0x090
Reset value: 0x0000 8000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
C2EWI
LA
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 C2EWILA: Wake-up on CPU2 illegal access interrupt enable
This bit is set and cleared by software
0: CPU2 wake-up on illegal access interrupt disabled (does not wake up CPU2 from low-
power modes).
1: CPU2 wake-up on illegal access interrupt enabled (wakes up CPU2 from low-power
modes).
Bits 14:0 Reserved, must be kept at reset value.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
NSS Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 NSS: sub-GHz SPI NSS control
This bit is set and cleared by software and is used to control the sub-GHz SPI NSS level from
software.
0: sub-GHz SPI NSS signal at level low
1: sub-GHz SPI NSS signal is at level high
