RM0453 Comparator (COMP)
631
21.6.3 COMP register map
Refer to Section 2.6 for the register boundary addresses.
Bit 0 EN: COMP2 enable
This bit is set and cleared by software. It switches COMP2 on.
0: COMP2 switched off
1: COMP2 switched on
Table 128. COMP register map and reset values
Offset Register name
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x00
COMP1_CSR
LOCK
VALUE
Res. Res. Res.
INMESEL[1:0]
Res.
SCALEN
BRGEN
Res.
BLANKING[2:0]
HYST[1:0]
POLARITY
Res. Res. Res. Res. Res. Res.
INPSEL[1:0]
INMSEL[2:0]
PWRMODE[1:0]
Res.
EN
Reset value 00 00 00 000000 0000000 0
0x04
COMP2_CSR
LOCK
VALUE
Res. Res. Res.
INMESEL[1:0]
Res.
SCALEN
BRGEN
Res.
BLANKING[2:0]
HYST[1:0]
POLARITY
Res. Res. Res. Res. Res.
WINMODE
INPSEL[1:0]
INMSEL[2:0]
PWRMODE[1:0]
Res.
EN
Reset value 00 00 00 000000 00000000 0
