Analog-to-digital converter (ADC) RM0453
540/1450 RM0453 Rev 5
Caution: When selecting CKMODE[1:0] = 11 (PCLK divided by 1), the user must ensure that the
PCLK has a 50% duty cycle. This is done by selecting a system clock with a 50% duty cycle
and configuring the APB prescaler in bypass modes in the RCC (refer to there Reset and
clock controller section). If an internal source clock is selected, the AHB and APB prescalers
do not divide the clock.
Table 103. Latency between trigger and start of conversion
(1)
1. Refer to the device datasheet for the maximum ADC_CLK frequency.
ADC clock source CKMODE[1:0]
Latency between the trigger event
and the start of conversion
HSI16, SYSCLK or
PLLPCLK
(2)
2. Selected with ADCSEL bitfield of the RCC_CCIPR register
00 Latency is not deterministic (jitter)
PCLK divided by 2 01
Latency is deterministic (no jitter) and equal to
3.25 ADC clock cycles
PCLK divided by 4 10
Latency is deterministic (no jitter) and equal to
3.125 ADC clock cycles
PCLK divided by 1 11
Latency is deterministic (no jitter) and equal to
3 ADC clock cycles
