RM0453 Rev 5 273/1450
RM0453 Power control (PWR)
285
6.6.8 PWR control register 5 (PWR_CR5)
This register is not reset when exiting Standby modes.
Access: three additional APB cycles are needed to write this register versus a standard APB
write.
Address offset: 0x01C
Reset value: 0x0000 0000
Bit 2 CWUF3: Clear wake-up flag 3
Setting this bit clears the WUF3 flag in the PWR_SR1 register. This bit is always read as 0.
Bit 1 CWUF2: Clear wake-up flag 2
Setting this bit clears the WUF2 flag in the PWR_SR1 register. This bit is always read as 0.
Bit 0 CWUF1: Clear wake-up flag 1
Setting this bit clears the WUF1 flag in the PWR_SR1 register. This bit is always read as 0.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
1514131211109876543210
SMPSEN
RFEOLEN
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 SMPSEN: SMPS step-down converter enable
This bit enables the SMPS step-down converter.
0: SMPS step-down converter SMPS mode disabled (LDO mode enabled)
1: SMPS step-down converter SMPS mode enabled
Caution: Before enabling the SMPS, the SMPS clock detection must be enabled
in SUBGHZ_SMPSC0R.CLKDE, if the application uses an external HSE clock
source (not coming from XO or TCXO but from another device).
Bit 14 RFEOLEN: sub-GHz radio end-of-life detector enable
0: Radio end-of-life detector disabled
1: Radio end-of-life detector enabled
Bits 13:0 Reserved, must be kept at reset value.
