Global security controller (GTZC) RM0453
84/1450 RM0453 Rev 5
address with a length defined through
GTZC_TZSC_MPCWM1_UPWWMR.LGTH[11:0]. Only the area which is also defined
as unprivileged in GTZC_TZSC_MPCWM1_UPWMR.LGTH[11:0] is unprivileged
writable.
Note: Where n represents the target memory (1 = Flash memory, 2 = SRAM1 and 3 = SRAM2).
Figure 6. Memory protection control water mark
3.4.5 Security illegal access controller (TZIC)
This block concentrates all illegal access source events. It is used only when the system is
security enabled (ESE = 1). When the system is non-secure (ESE = 0), the generation of an
illegal access interrupt is blocked in hardware.
TZIC allows the trace of which event has trigged the illegal interrupt tzic_ila_it. Register
masks are available in TZIC_IER to filter unwanted events. Enabled illegal events generate
an interrupt to the secure CPU2 NVIC (TZIC_ILA).
For each illegal event source, a status flag and a clear bit exist (respectively within
TZIC_MISR and TZIC_ICR registers). The reset value of the enable register TZIC_IER is
such that all illegal events are enabled.
3.4.6 Power-on/reset state
The power-on and reset state of TZSC clear all bits of SECCFGR1 and PRIVCFGR1
registers to 0, which respectively means non-secure and unprivileged.
Concerning the internal memories, the reset values of the TZSC MPCWMn_UPWMR and
MPCWMn_UPWWMR registers are set to 0x0FFF 0000, making the complete internal
memories unprivileged.
CPU1 non-secure privileged boot code can program the non-secure privileged attributes,
making components non-secure privileged as needed.
CPU2 secure privileged boot code can program the secure privileged attributes, making
components secure privileged as needed.
MSv61500V1
Privileged
Unprivileged
read, execute
and
writable
Privileged and
unprivileged
read, execute
UPWMR.LGTH[11:0]
UPWWMR.LGTH[11:0]
Memory base address
