5.10.61 Sub-GHz radio register map
Table 42. SUBGHZ register map and reset values
Offset Register name 7 6 5 4 3 2 1 0
0x6AC
SUBGHZ_GBSYNCR Res.
SBITSYNCEN
RXDINV
BITSYNCDIS
Res. Res. Res. Res.
Reset value 0 0 0
0x6AC-
0x6B4
Reserved Reserved
0x6B8
SUBGHZ_GPKTCTL1AR Res. Res.
SYNCDETEN
CONTTX INFSQEQSEL[1:0]
INFSSQEQEN
WHITEINI[8]
Reset value 100001
0x6B9
SUBGHZ_GWHITEINIRL WHITEINI[7:0]
Reset value 00000000
0x6BC
SUBGHZ_GCRCINIRH CRCINI[15:8]
Reset value 00011101
0x6BD
SUBGHZ_GCRCINIRL CRCINI[7:0]
Reset value 00001111
0x6BE
SUBGHZ_GCRCPOLRH CRCPOL[15:8]
Reset value 00010000
0x6BF
SUBGHZ_GCRCPOLRL CRCPOL[7:0]
Reset value 00100001
0x6C0
SUBGHZ_GSYNCR0 SYNCWORD[63:56]
Reset value 10010111
0x6C1
SUBGHZ_GSYNCR1 SYNCWORD[55:48]
Reset value 00100011
0x6C2
SUBGHZ_GSYNCR2 SYNCWORD[47:40]
Reset value 01010010
0x6C3
SUBGHZ_GSYNCR3 SYNCWORD[39:32]
Reset value 00100101
0x6C4
SUBGHZ_GSYNCR4 SYNCWORD[31:24]
Reset value 01010110
0x6C5
SUBGHZ_GSYNCR5 SYNCWORD[23:16]
Reset value 01010011
0x6C6
SUBGHZ_GSYNCR6 SYNCWORD[15:8]
Reset value 01100101
0x6C7
SUBGHZ_GSYNCR7 SYNCWORD[7:0]
Reset value 01100100
0x6C8-
0x73C
Reserved Reserved
0x740
SUBGHZ_LSYNCRH SYNCWORD[15:8]
Reset value 00010100
0x741
SUBGHZ_LSYNCRL SYNCWORD[7:0]
Reset value 00100100
0x742-
0x818
Reserved Reserved
