STMicroelectronics STM32WL5 Series - Page 227

RM0453 Rev 5 227/1450
RM0453 Sub-GHz radio (SUBGHZ)
227
Refer to Section 2.6 for the register boundary addresses.
0x819
SUBGHZ_RNGR3 RNDATA[31:24]
Reset value 00000000
0x81A
SUBGHZ_RNGR2 RNDATA[23:16]
Reset value 00000000
0x81B
SUBGHZ_RNGR1 RNDATA[15:8]
Reset value 00000000
0x81C
SUBGHZ_RNGR0 RNDATA[7:0]
Reset value 00000000
0x89B
SUBGHZ_AGCRSSIC0R Res. MODE MC LENGTH[2:0] Res. Res.
Reset value 00000
0x820-
0x8AB
Reserved Reserved
0x8AC
SUBGHZ_RXGAINCR SENSI_ADJUST[5:0]. PMODE[1:0]
Reset value 10010100
0x8B0-
0x8E6
Reserved Reserved
0x8E7
SUBGHZ_PAOCPR Res. Res. OCP[5:0]
Reset value 011000
0x8E8 -
0x910
Reserved Reserved
0x911
SUBGHZ_HSEINTRIMR Res. Res. TRIM[5:0]
Reset value 010010
0x912
SUBGHZ_HSEOUTTRIMR Res. Res. TRIM[5:0]
Reset value 010010
0x913-
0x915
Reserved Reserved
0x916
SUBGHZ_SMPSC0R Res. CLKDE Res. Res. Res. Res. Res. Res.
Reset value 0
0x917-
0x919
Reserved Reserved
0x91A
SUBGHZ_PCR Res. CLE CLV[1:0] Res. Res. Res. Res.
Reset value 1 0 1
0x91B-
0x920
Reserved Reserved
0x91F
SUBGHZ_REGDRVTSTR Res. Res. Res. Res. TRIM[2:0] EN
Reset value 1000
0x923
SUBGHZ_SMPSC2R Res. Res. Res. Res. Res. DRV[1:0] Res.
Reset value 11
Table 42. SUBGHZ register map and reset values (continued)
Offset Register name 7 6 5 4 3 2 1 0
