Sub-GHz radio (SUBGHZ) RM0453
208/1450 RM0453 Rev 5
5.10.2 Sub-GHz radio ramp-up LSB register (SUBGHZ_RAM_RAMPUPL)
Address offset: 0x0F1
Reset value: 0x00
5.10.3 Sub-GHz radio ramp-down MSB register
(SUBGHZ_RAM_RAMPDNH)
Address offset: 0x0F2
Reset value: 0x00
5.10.4 Sub-GHz radio ramp-down LSB register
(SUBGHZ_RAM_RAMPDNL)
Address offset: 0x0F3
Reset value: 0x00
5.10.5 Sub-GHz radio frame limit MSB register
(SUBGHZ_RAM_FRAMELIMH)
Address offset: 0x0F4
Reset value: 0x00
76543210
RAMPUP[7:0]
rw rw rw rw rw rw rw rw
Bits 7:0 RAMPUP[7:0]: Ramp-up LSB bits
76543210
RAMPDN[15:8]
rw rw rw rw rw rw rw rw
Bits 7:0 RAMPDN[15:8]: Ramp-down MSB bits
76543210
RAMPDN[7:0]
rw rw rw rw rw rw rw rw
Bits 7:0 RAMPDN[7:0]: Ramp-down LSB bits
76543210
FRAMELIMH[15:8]
rw rw rw rw rw rw rw rw
Bits 7:0 FRAMELIMH[15:8]: frame limit MSB bits
