STMicroelectronics STM32WL5 Series User Manual

Reset and clock control (RCC) RM0453
304/1450 RM0453 Rev 5
7.2.21 Peripheral clocks enable
Most peripheral bus and kernel clocks can be individually enabled per CPU.The
RCC_AHBxENR and RCC_APBxENRy registers enable peripheral clocks for CPU1.
RCC_C2_AHBxENR and RCC_C2_APBxENR registers enable peripheral clocks for CPU2.
The peripheral clocks follow the CPUs state for which it is enabled and the system state
(see the table below). The RTC kernel clock is enabled by the RTCEN bit and does not
depend on the CPUs state nor the system state.
Peripheral bus clock activity during the CPU Sleep mode is controlled by the xxxxSMEN bit
of the RCC_AHBxSMENR and RCC_APBxSMENRy registers for CPU1, and
RCC_C2_AHBxSMENR and RCC_C2_APBxSMENRy registers for CPU2.The peripheral
bus clock during Sleep mode follows the CPUs state for which it is enabled (see the table
below).
When the peripheral bus clock is not active, read or write accesses to the peripheral
registers are not supported.
When the peripheral kernel clock is not active, the peripheral functionality is stopped.
The enable bits have a synchronization mechanism to create a glitch free clock for the
peripheral. After the enable bit is set, there is a two clock cycles delay before the clock is
active in the peripheral.
Caution: Just after enabling a clock for a peripheral, the software must wait for a delay before
accessing the peripheral registers.
Table 61. Peripheral clock enable
xxxEN xxxSMEN
CPU
mode
System
mode
Bus clock Kernel clock
(1)
1. Only the I2C, LPTIM, USART, LPUART, True RNG, ADC and SPI I2S peripherals have a kernel clock
controlled by xxxEN and xxxSMEN. The RTC has a kernel clock controlled by RTCEN and does not
depend on xxxEN and xxxSMEN.
0
x
Any Any Stopped Stopped
1
CRun Run Clocked
(2)
2. Only when the xxxEN bit associated with the CPU in CRun is enabled.
Clocked
0
CSleep
and
CStop
Run Stopped Clocked
1
CSleep Run Clocked
(3)
3. Only when both the xxxEN bit and xxxSMEN bit associated with the CPU in CSleep are enabled.
Clocked
CStop
Run Stopped Clocked
Stop Stopped
Clocked when from HSI16, LSI, or LSE
Stopped when from bus clock, SYSCLK,
PLL clocks, or MSI clocks
xx
Standby or
Shutdown
Stopped Stopped
(4)
4. The RTC kernel clock when selected from LSI or LSE is still clocked in Standby mode and still clocked in
VBAT and Shutdown modes when LSE is selected.
