24.7.5 PKA register map
Refer to Section 2.6 on page 71 for the register boundary addresses.
Table 175. PKA register map and reset values
Offset
Register
name
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12
11
10
9 8 7 6 5 4 3 2 1 0
0x000
PKA_CR
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ADDRERRIE
RAMERRIE
Res.
PROCENDIE
Res. Res. Res.
MODE[5:0]
Res. Res. Res. Res. Res. Res.
START
EN
Reset value 00 0 000000 00
0x004
PKA_SR
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ADDRERRF
RAMERRF
Res.
PROCENDF
BUSY
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
Reset value 0 0 0 0
0x008
PKA_CLRFR
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
ADDRERRFC
RAMERRFC
Res.
PROCENDFC
Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res. Res.
Reset value 0 0 0
