STMicroelectronics STM32WL5 Series User Manual

Sub-GHz radio (SUBGHZ) RM0453
224/1450 RM0453 Rev 5
5.10.57 Sub-GHz radio SMPS control 0 register (SUBGHZ_SMPSC0R)
Address offset: 0x916
Reset value: 0x00
5.10.58 Sub-GHz radio power control register (SUBGHZ_PCR)
Address offset: 0x91A
Reset value: 0x50
This register is retained in Sleep mode but lost in Deep-Sleep mode.
76543210
Res. CLKDE Res. Res. Res. Res. Res. Res.
rw
Bit 7 Reserved, must be kept at reset value.
Bit 6 CLKDE: SMPS clock detection enable
SMPS clock detection must be enabled before enabling the SMPS, if the application uses an
external HSE clock source (not coming from XO or TCXO but from another device).
0: SMPS clock detection disabled
1: SMPS clock detection enabled
Bits 5:0 Reserved, must be kept at reset value.
76543210
Res. CLE CLV[1:0] Res. Res. Res. Res.
rw rw rw
Bit 7 Reserved, must be kept at reset value.
Bit 6 CLE: Power-supply current limiter enable
0: power-supply current limiter disabled (unlimited current)
1: power-supply current limiter enabled (current limited according to CLV[1:0])
Bits 5:4 CLV[1:0]: Power-supply current limiter value
When the power-supply current limiter is enabled by CLEN, these bits define the maximum
current limiting level.
0x0: power-supply current limiting level 25 mA
0x1: power-supply current limiting level 50 mA (default)
0x2: power-supply current limiting level 100 mA
0x3: power-supply current limiting level 200 mA
Bits 3:0 Reserved, must be kept at reset value.
