Sub-GHz radio (SUBGHZ) RM0453
220/1450 RM0453 Rev 5
5.10.45 Sub-GHz radio AGC reset configuration register
(SUBGHZ_AGCGFORSTCFGR)
Address offset: 0x8B8
Reset value: 0x14
5.10.46 Sub-GHz radio AGC reset power threshold register
(SUBGHZ_AGCGFORSTPOWTHR)
Address offset: 0x8B9
Reset value: 0x0A
5.10.47 Sub-GHz radio Tx clamp register (SUBGHZ_TXCLAMPR)
Address offset: 0x8D8
Reset value: 0x00
Bits 1:0 PMODE[1:0]: Receiver power mode selection between normal mode and power saving mode
00: power saving mode (reduced sensitivity)
01: boost mode level1 active (improves sensitivity at detriment of power consumption)
10: boost mode level2 active (improves a set further sensitivity at detriment of power
consumption)
Others: boost mode (best receiver sensitivity)
76543210
EN[7:0]
rw rw rw rw rw rw rw rw
Bits 7:0 EN[7:0]: Enable the reset generation for frequency-offset estimation
76543210
PWRTHR[7:0]
rw rw rw rw rw rw rw rw
Bits 7:0 PWRTHR[7:0]: Power threshold reset for frequency-offset estimation
76543210
Res Res Res Res Res Res Res Res
Bits 7:0 Reserved, must be kept at reset value.
