AMD K5

Bus Cycle Timing 5-193
18524C/0—Nov1996 AMD-K5 Processor Technical Reference Manual
Figure 5-27A. Stop-Grant and Stop-Clock Modes Part 1
CLK
A31–A3
ADS
BE7–BE0
BRDY
CACHE
D/C
D63–D0
KEN
LOCK
M/IO
STPCLK
W/R
CLK
STPCLK
Asserted
Stop Grant
Special Cycle
Stop
Clock
State
