2.9 HANDLING OF ROTATING BLADE,
SHAFT AND DRIVING BELT
• Do not put a hand or a foot into the tractor’s rotating
blade or PTO shaft.
• Do not wear loose clothing.
• Be careful not to get caught by the rotating engine
cooling fan.
• You can be seriously injured if your hand or clothes
is caught by the rotating fan belt or A/C belt.
T46W024A
T46W025A
T46W026A
T46W023A
2.10 PREVENTING SCALDING
• Do not open the radiator cap when the radiator is
hot. Hot coolant or steam can surge leading to se-
rious scalding.
• Check the surface temperature of the container be-
fore draining the engine oil, transmission fluid,
coolant, etc. If it is hot, let it cool down before drain-
ing it. There is danger of burning.
• Perform any service on the engine parts (muffler,
exhaust manifold, turbocharger, etc.) only when they
have cooled.
T46W027A
T46W028A
SAFETY FIRST - SAFETY TIPS
