CK22/CK22H
2.4.8 CRANKSHAFT
2.4.9 FUEL INJECTION NOZZLES
20.03 mm
0.7885 in.
-
-
0.15 mm
0.0059 in.
0.05 mm
0.0020 in.
Crankshaft alignment
O.D. of crankshaft journals
I.D. of crankshaft bearing 1
I.D. of crankshaft bearing 2
Clearance between crankshaft
journals and bearing 1
Clearance between crankshaft
journals and bearing 2
O.D. of crankpins
I.D. of crankpin bearings
Clearance between
crankpins and bearings
End play of crankshaft
0.02 mm
0.0008 in.
47.934 ~ 47.950 mm
1.8872 ~ 1.8878 in.
48.068 ~ 48.138 mm
1.8924 ~ 1.8952 in.
47.980 ~ 48.006 mm
1.8890 ~ 1.8900 in.
0.118 ~ 0.204 mm
0.0046 ~ 0.0080 in.
0.030 ~ 0.072 mm
0.0012 ~ 0.0028 in.
39.959 ~ 39.975 mm
1.5732 ~ 1.5738 in.
39.994 ~ 40.020 mm
1.5746 ~ 1.5756 in.
0.035 ~ 0.061 mm
0.0014 ~ 0.0024 in.
0.15 ~ 0.31 mm
0.0059 ~ 0.0122 in.
0.08 mm
0.0031 in.
-
-
-
0.20 mm
0.0079 in.
0.20 mm
0.0079 in.
-
-
0.20 mm
0.0079 in.
0.5 mm
0.0197 in.
Opening pressure
Fuel tightness of nozzle valve seat
14.2 ~ 15.2 MPa
145 ~ 155 kgf/cm²,
2,062 ~ 2,204 psi.
Dry nozzle at 12.7 MPa
130 kgf/cm², 1,848.6 psi.
-
-
2.4.7 PISTONS
I.D. of piston bosses
O.D. of piston pin
I.D. of connecting rod small end bushings (fitted)
Clearance between piston pin
and small end bushings
Connecting rod alignment
20.000 ~ 20.013 mm
0.7874 ~ 0.7879 in.
20.002 ~ 20.011 mm
0.7875 ~ 0.7878 in.
20.025 ~ 20.040 mm
0.7884 ~ 0.7890 in.
0.014 ~ 0.038 mm
0.0006 ~ 0.0015 in.
0.02 mm
0.0008 in.
Reference Value Allowable Limit
Item
Reference Value Allowable Limit
Item
Reference Value Allowable Limit
Item
ENGINE - SPECIFICATIONS
