CK22/CK22H
Symptom
Noise from trans-
mission
Gear slip out of
mesh
Differential lock
cannot be set
Differential lock pedal
does not return
Probable Cause
• Transmission oil insufficient
• Gear worn or broken
• Improper backlash between ring gear and spiral
bevel pinion shaft
• Improper backlash between differential pinion and
differential side gear
• Bearings worn
• Shift fork spring tension insufficient
• Shift fork or shifter worn
• Shift fork bent
• Differential lock pedal play excessive
• Differential lock shift fork broken
• Differential lock clutch broken
• Differential lock spring broken or fall
• Differential lock spring tension insufficient
Solution
Refill
Replace
Adjust
Adjust
Replace
Replace
Replace
Replace
Adjust
Replace
Replace
Replace or assembly
Replace
3.1 MECHANICAL TRANSMISSION (MANUAL)
3. TROUBLESHOOTING
TRANSMISSION - TROUBLESHOOTING
