Daedong CK22 - Camshaft; Piston Rings; Valve Rocker Arms

2-9
DS35-W00 May. 2007
CLUTCHCLUTCH CLUTCHCLUTCH
CLUTCH
TRANSMISSIONTRANSMISSION TRANSMISSIONTRANSMISSION
TRANSMISSION
ENGINEENGINE ENGINEENGINE
ENGINE
HSTHST HSTHST
HST
FRONT AXLEFRONT AXLE FRONT AXLEFRONT AXLE
FRONT AXLE
STEERINGSTEERING STEERINGSTEERING
STEERING
BARKEBARKE BARKEBARKE
BARKE
ELECTRICELECTRIC ELECTRICELECTRIC
ELECTRIC
INDEXINDEX INDEXINDEX
INDEX
HYDRAULICHYDRAULIC HYDRAULICHYDRAULIC
HYDRAULIC
GENERALGENERAL GENERALGENERAL
GENERAL
REAR AXLEREAR AXLE REAR AXLEREAR AXLE
REAR AXLE
CK22/CK22H
2.4.5 CAMSHAFT
O.D. of camshaft bearing journal
I.D. of camshaft bearing
Clearance between camshaft
bearing journals and bearings
Alignment of camshaft
Cam height
Gear backlash
32.934 ~ 32.950 mm
1.2966 ~ 1.2972 in.
33.000 ~ 33.025 mm
1.2992 ~ 1.3002 in.
0.050 ~ 0.091 mm
0.0020 ~ 0.0036 in.
-
26.75 mm
1.0530 in.
26.88 mm
1.0583 in.
0.042 ~ 0.115 mm
0.0017 ~ 0.0045 in.
-
-
0.15 mm
0.0020 in.
0.05 mm
0.0020 in.
26.83 mm
1.0563 in.
26.88 mm
1.0583 in.
0.2 mm
0.0079 in.
Intake
Exhaust
2.4.6 PISTON RINGS
Ring gap
Side clearance of ring
in groove
0.15 ~ 0.30 mm
0.0059 ~ 0.0118 in.
0.30 ~ 0.45 mm
0.0118 ~ 0.0177 in.
0.20 ~ 0.35 mm
0.0079 ~ 0.0138 in.
-
0.04 ~ 0.08 mm
0.0016 ~ 0.0031 in.
0.02 ~ 0.06 mm
0.0008 ~ 0.0024 in.
1.25 mm
0.0492 in.
1.25 mm
0.0492 in.
1.25 mm
0.0492 in.
-
-
-
Top ring
2nd ring
Oil ring
Top ring
2nd ring
Oil ring
Reference Value Allowable Limit
Item
Reference Value Allowable Limit
Item
O.D. of rocker arm shafts
I.D. of rocker arm bushings
Clearance between rocker arm shafts and
bushings
Adjustment of compression release
2.4.4 VALVE ROCKER ARMS
-
-
0.12 mm
0.0047 in.
-
12.955 ~ 12.980 mm
0.5100 ~ 0.5110 in.
13.000 ~ 13.025 mm
0.5118 ~ 0.5128 in.
0.02 ~ 0.07 mm
0.0008 ~ 0.0027 in.
0.750 ~ 1.125 mm
0.0295 ~ 0.0443 in.
Reference Value Allowable Limit
Item
ENGINE - SPECIFICATIONS
