CK22/CK22H
2.7 3 POINT HITCH LIFTING SYSTEM
2.7.1 OPERATING OF MLS (MITA LOAD SENSING VALVE)
196W932B
A. OPERATION OF MLS CONTROL VALVE
The Control Valve has three distinct functioning phases:
(A) Charge (C) Neutral position 109 ± 0.15
(B) Discharge
HYDRAULIC SYSTME - OPERATING PRINCIPLE
