CK22/CK22H
4.15 JOY-STICK VALVE
1. Remove the hydraulic tube P1 (1), hydraulic tube
P2 (2), and return tube (3).
2. Remove the bolts and the valve.
3. Remove the valve support (4).
196W4D5A
(1) Hydraulic tube P1 (3) Return tube
(2) Hydraulic tube P2 (4) Valve support
Item
Joint bolt
Tightening torque
39.2 ~ 44.1 Nm
4.0 ~ 4.5 kgf-m
28.9 ~ 32.5 lb-ft
TRANSMISSION - SERVICING
