CK22/CK22H
8.1.7 CHECKING BRAKE PEDALS AND
CLUTCH PEDAL
1. Examine the brake and clutch pedals for free travel,
and smooth operation.
2. Adjust if necessary.
(See “Adjusting Clutch and Brake Pedal” in every
100 hours maintenance.)
NOTE:
Brake pedals should match each other when
depressed.
8.1.8 CHECKING GAUGES, METER AND
EASY CHECKER
1. Examine the instrument panel for broken gauge(s),
meter(s) and check lamps.
2. Replace if broken.
GENERAL - CHECK AND MAINIENANCE
