2.4.15 TIGHTENING TORQUE
Indicate the bolts with  mark and manually tighten first.
Item
Head bolt, nut
 Bearing case bolt 1
 Bearing case bolt 2
 Flywheel bolt
 Connecting rod bolt
Rocker arm bracket sink bolt
Idle gear shaft bolt
Glow plug (no lubrication)
Waste oil plug
Nozzle holder
Overflow pipe nut
Oil switch
Fuel supply limit cap nut
Idle limit fixing nut
Injection pipe nut
Crankshaft nut
lb-ft
43.4 ~ 47.0
21.7 ~ 25.3
21.7 ~ 25.3
39.7 ~ 43.4
19.5 ~ 22.4
17.4 ~ 20.3
5.7 ~ 7.2
14.4 ~ 18.1
23.9 ~ 27.5
36.1 ~ 50.5
21.7 ~ 25.3
1.0 ~ 1.4
10.8 ~ 14.5
20.3 ~ 25.3
10.1 ~ 11.5
18.0 ~ 25.3
101.2 ~ 115.7
kgf-m
6.0 ~ 6.5
3.0 ~ 3.5
3.0 ~ 3.5
5.5 ~ 6.0
2.7 ~ 3.1
2.4 ~ 2.8
0.8 ~ 1.0
2.0 ~ 2.5
3.3 ~ 3.8
5.0 ~ 7.0
3.0 ~ 3.5
0.14 ~ 0.20
1.5 ~ 2.0
2.8 ~ 3.5
1.4 ~ 1.6
2.5 ~ 3.5
14 ~ 16
Nm
58.8 ~ 63.7
29.4 ~ 34.3
29.4 ~ 34.3
53.9 ~ 58.8
26.5 ~ 30.4
23.5 ~ 27.5
7.8 ~ 9.8
19.6 ~ 24.5
32.4 ~ 37.3
49.0 ~ 68.6
29.4 ~ 34.3
1.4 ~ 1.9
14.7 ~ 19.6
27.5 ~ 34.3
13.7 ~ 15.7
24.5 ~ 34.3
137.2 ~ 156.9
Bis
Taper screw
