CK22/CK22H
• Improper backlash between 7T spiral bevel pinion and
bevel gear.
• Improper backlash between differential pinion and
differential side gear.
• Bearings worn.
• Insufficient or improper type or transmission fluid used.
• Differential pinions or differential side gears worn or
damaged.
• Differential lock binding (does not disengage)
• Bearings worn.
• Differential lock shift fork changed.
• Differential lock arm damaged.
• Differential lock pedal return spring weaken or damaged.
Solution
Symptom Items
Excessive or unusual
noise at all times
Noise while turning
Differential lock can
not be set
Differential lock
pedal does not
return
Adjust
Adjust
Replace
Replenish or replace
Replace
Replace
Replace
Replace
Replace
Replace
3. TROUBLESHOOTING
REAR AXLE - TROUBLESHOOTING
