CK22/CK22H
1.2 ENGINE EPA DECAL
This aluminum decal is riveted on the engine cylinder
head cover. This provides the information such as model
number, displacement, rated output, valve clearance,
injection timing, etc.
This decal represents that this engine is in compliance
with the U.S.EPA and California (CARB) exhaust emis-
sion regulation.
1.3 BAR CODE FOR ENGINE NUMBER
The bar code for the DAEDONG engine number is
located on the intake manifold.
1.4 ENGINE NUMBER ASSIGNMENT
STANDARD
The engine number is also stamped near the fuel injec-
tion pump on the cylinder block, in case the bar code
is not available due to damage.
T46W202A
For example, FD4000001 means that this engine is
the first manufactured unit, 3B183 LXM, in 2006.
• The engine number is necessary information that
is requested on the warranty registration form.
This number should be on the form as well as the
tractor serial number and the amount of time used.
IMPORTANT
Year of manufacturing
Engine model
Serial number
F D 4 0 0 0 0 0 1
D40
D41
D22
D23
D24
D25
D38
D39
3B183LXM
3B183LXH
4A200LXM
4A200LXH
4A220LXM
4A220LXH
4B243LXM
4B243LXH
...
1998
1999
2000
2001
2002
2003
2004
2005
2006
2007
...
...
8
9
0
1
2
3
D
E
F
G
...
5DCLL02.2D87
5DCLL02.2D87
33.6 kW a 2600 RPM
33.6 kW a 2600 RPM
850
850
2.197
2.197
18
18
e11*97/68DA*2002/88*0182*03
e11*97/68DA*2002/88*0182*03
2005
2005
0.25
0.25
0.3
0.3
IMPORTANT ENGINE INFORMATION
Engine Family:
5DCLL02.2D87
33.6 kW a 2600 RPM 850 RPM
2.197 L
18 DEG BTDC
Inlet 0.25 Exhaust 0.3
Engine Type:
Advertised Power:
Valve Clearance(mm):
Adjustments should be made when the engine is at normal operating
temperature with transmission in neutral.
This engine conforms to
2005 U.S EPA andCalifornia regulations
for off-road compression-ignition engines.
This engine is certified to operate on commercially available diesel
fuel. Refer to owner's manual for maintemance specifications and
adjustmints.
Injection Timing:
Displacement:
E6305-99506
Idle Min:
e11*97/68DA*2002/88*0182*03
ENGINE - ENGINE IDENTIFICATION
