• Brake pedal play unevenly adjusted.
• Brake disc worn.
• Cam plate warped.
• Brake pedal play too small.
• Brake pedal return spring weaken or broken.
• Brake camshaft rusted.
• Brake pedal play excessive.
• Brake disc worn.
• Cam plate wraped.
• Brake lever damaged.
• Transmission fluid improper.
Solution
3. TROUBLESHOOTING
Symptom Items
Uneven braking force
Brake drags
Poor braking force
Adjust
Replace
Replace
Adjust
Replace
Repair
Adjust
Replace
Replace
Replace
Change
BRAKE - TROUBLESHOOTING
