CK22/CK22H
Solution
Adjust
Adjust
Replace
Adjust
Replace
Tighten
Bleed
Replace
Replace
Replace
Replace
Reassemble
Adjust or replace
Replenish
Replace
Replace
Adjust
Symptom
Front wheels wander to
right or left
Front wheel can not be
driven
Noise
Provable Causes
• Tire pressure uneven
• Improper toe-in adjustment (improper alignment)
• Clearance between front axle case boss and front axle
bracket (front, rear) bushing excessive.
• Front axle rocking force too small
• Front wheel sway excessive
• Tie-rod end loose
• Air sucked in power steering circuit
• Propeller shaft broken
• Front wheel drive gears in transmission broken
• Front differential gear broken
• Shift fork broken
• Coupling displaced
• Gear backlash excessive
• Oil insufficient
• Bearings damaged or broken
• Gears damaged or broken
• Spiral bevel pinion shaft turning force improper
3. TROUBLESHOOTING
FRONT AXLE - TROUBLESHOOTING
