Daedong CK22 - Brake

TABLE OF CONTENTS
BRAKE
CK22/CK22H
1. SPECIFICATIONS .................................................................... 7-2
2. OPERATING PRINCIPLE ........................................................ 7-3
2.1 Structure ............................................................................ 7-3
2.2 Features of wet disc brakes............................................. 7-4
3. TROUBLESHOOTING .............................................................. 7-5
4. SERVICING ............................................................................... 7-6
4.1 Disassembling and assembling ....................................... 7-6
4.1.1 Draining the transmission fluid ............................. 7-6
4.1.2 Hand brake (CK22-EU) ........................................... 7-7
4.1.3 Separating rops and tires ...................................... 7-8
4.1.4 Fender ...................................................................... 7-8
4.1.5 Disassembling and assembling ............................ 7-9
4.1.6 Disassembling brake assembly ............................ 7-9
4.2 Inspection for overhaul .................................................... 7-10
4.2.1 Checking disassembling and servicing .............. 7-10
4.2.2 Brake disc wear .................................................... 7-10
4.2.3 Plate wear ............................................................. 7-10
