CK22/CK22H
1. SPECIFICATIONS
1.1 GENERAL SPECIFICATIONS
1. Fluid ............................... SAE 90 gear oil or transmission fluid
• Transmission fluid specification: DAEDONG (TF65)
Exxon (Mobilfluid 423 or 424)
BP (Tractran UTH)
Shell (DONAX-TD/TD Plus)
2. Oil capacity for front axle .................. 3.1
0.82 u.s.gal
3. Max. steering angle ........................... 51 ~ 53° (based on the inner side of wheels)
4. Toe-in.................................................. 2 ~ 8 mm (0.079 ~ 0.315 in.)
• The same DAEDONG transmission fluid is filled in the front axle
in the factory for easy manufacturing process. The SAE90 gear
oil mentioned above cannot be used in the transmission or any
hydraulic system. If such oil is used in the transmission, it can
cause the abnormal noise and damage the hydraulic system
components.
IMPORTANT
FRONT AXLE - SPECIFICATIONS
