CK22/CK22H
2.1 POWER TRAIN DIAGRAM
2. OPERATING PRINCIPLE
196W4C1B
(1) Hydraulic transmission section (2) High-Low range shift section
(3) Mid PTO shift section (4) Rear PTO shift section
(5) Overrunning clutch section (6) Front Wheel drive section
HST - OPERATING PRINCIPLE
