CK22/CK22H
196W945A
6. Install the cables (10, 11), pins (26) and screws
(30) into the assembly and tighten its locknut.
Waterproof cap prearranged for remote control with
flexible cable.
(1) Socket head cap screw
Item
Socket head cap screw
Tightening torque
6.6 Nm
0.7 kgf-m
4.9 lb-ft
HYDRAULIC SYSTME - SERVICING
To Next Page
