Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-42
DC SC2020
6.3.6 NVM 742_Paper Handling List
Version 1.1
General
742-064 Side Regi Adjustment (Tray1/Side1/
Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray1/Side1/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-065 Side Regi Adjustment (Tray2/Side1/
Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-066 Side Regi Adjustment
(Tray2/Side1/Heavyweight1/126[mm/
s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Heavyweight1/126[mm/s])_0.105[mm/
step] Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-067 Side Regi Adjustment
(Tray2/Side1/Heavyweight1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Heavyweight1/63[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-068 Side Regi Adjustment
(Tray2/Side1/Extra Heavyweight/
63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Extra Heavyweight/63[mm/s])_0.105[mm/
step] Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-069 Side Regi Adjustment (Tray2/Side1/
Labels1/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Labels1/126[mm/s])_0.105[mm/
step]Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-070 Side Regi Adjustment (Tray2/Side1/
Labels1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/Labels1/63[mm/s])_0.105[mm/
step]Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-071 Side Regi Adjustment (Tray2/Side1/HW
Labels/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side1/HW Labels/63[mm/s])_0.105[mm/
step]Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-072 Side Regi Adjustment
(MSI/Side1/Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-073 Side Regi Adjustment
(MSI/Side1/Heavyweight1/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Heavyweight1/126[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-074 Side Regi Adjustment
(MSI/Side1/Heavyweight1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Heavyweight1/63[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-075 Side Regi Adjustment
(MSI/Side1/Extra Heavyweight/63[mm/
s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Extra Heavyweight/63[mm/s])_0.105[mm/
step] Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-076 Side Regi Adjustment (MSI/Side1/
Labels1/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Labels1/126[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-077 Side Regi Adjustment (MSI/Side1/
Labels1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Labels1/63[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
