05/2014
6-43
DC SC2020
General
6.3.6 NVM 742_Paper Handling List
Version 1.1
742-078 Side Regi Adjustment (MSI/Side1/
Labels2/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side1/Labels2/63[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-079 Side Regi Adjustment (Tray1/Side2/
Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray1/Side2/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-080 Side Regi Adjustment (Tray2/Side2/
Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side2/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-081 Side Regi Adjustment
(Tray2/Side2/Heavyweight1/126[mm/
s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side2/Heavyweight1/126[mm/s])_0.105[mm/
step] Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-082 Side Regi Adjustment
(Tray2/Side2/Heavyweight1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (Tray2/Side2/Heavyweight1/63[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-083 Side Regi Adjustment
(MSI/Side2/Plain/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side2/Plain/126[mm/s])_0.105[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-084 Side Regi Adjustment
(MSI/Side2/Heavyweight1/126[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side2/Heavyweight1/126[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-085 Side Regi Adjustment
(MSI/Side2/Heavyweight1/63[mm/s])
0 -50 50 Main Scanning Direction Side Regi Adjustment (MSI/Side2/Heavyweight1/63[mm/s])_0.105[mm/step]
Adjustment
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-086 Side Regi Adjustment
(UI Adjustment ValueMSI)
0 -4 4 Main Scanning Direction from the UI Side Regi Adjustment (MSI)_0.525[mm/step] Adjustment
(=0.105mm/stepX5step)
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-087 Side Regi Adjustment
(UI Adjustment Value Tray1)
0 -4 4 Main Scanning Direction from the UI Side Regi Adjustment (Tray1)_0.525[mm/step] Adjustment
(=0.105mm/stepX5step)
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-088 Side Regi Adjustment
(UI Adjustment Value Tray2)
0 -4 4 Main Scanning Direction from the UI Side Regi Adjustment (Tray2)_0.525[mm/step] Adjustment
(=0.105mm/stepX5step)
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-089 Side Regi Adjustment
(UI Adjustment Value Duplex)
0 -4 4 Main Scanning Direction from the UI Side Regi Adjustment (Duplex)_0.525[mm/step] Adjustment
(=0.105mm/stepX5step)
*Adjusting the value in the plus (+) direction makes the left margin narrower.
OO
742-090 Side Regi Adjustment
(Tray2 Delivery Adjustment Value)
0 -50 50 Side Regi Adjustment Value when delivering the Tray Module (Tray2)_0.105[mm/step] units X O
742-091 Lead Regi Adjustment
(Tray1/Plain/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray1/Plain/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-092 Lead Regi Adjustment
(Tray2/Plain/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Plain/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
To Next Page
