Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-44
DC SC2020
6.3.6 NVM 742_Paper Handling List
Version 1.1
General
742-093 Lead Regi Adjustment
(Tray2/Heavyweight1/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Heavyweight1/126[mm/s])_0.126[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-094 Lead Regi Adjustment
(Tray2/Heavyweight1/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Heavyweight1/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-095 Lead Regi Adjustment
(Tray2/Extra Heavyweight/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Extra Heavyweight/63[mm/s])_0.126[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-096 Lead Regi Adjustment
(Tray2/Labels1/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Labels1/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-097 Lead Regi Adjustment
(Tray2/Labels1/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Labels1/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-098 Lead Regi Adjustment
(Tray2/Labels2/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Tray2/Labels2/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-099 Lead Regi Adjustment
(MSI/Plain/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Plain/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-100 Lead Regi Adjustment
(MSI/Heavyweight1/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Heavyweight1/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-101 Lead Regi Adjustment
(MSI/Heavyweight1/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Heavyweight1/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-102 Lead Regi Adjustment
(MSI/Extra Heavyweight/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Extra Heavyweight/63[mm/s])_0.126[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-103 Lead Regi Adjustment
(MSI/Labels1/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Labels1/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-104 Lead Regi Adjustment
(MSI/Labels1/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Labels1/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-105 Lead Regi Adjustment
(MSI/Labels2/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (MSI/Labels2/63[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-106 Lead Regi Adjustment
(Duplex/Plain/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Duplex/Plain/126[mm/s])_0.126[mm/step] Adjustment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-107 Lead Regi Adjustment
(Duplex/Heavyweight1/126[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Duplex/Heavyweight1/126[mm/s])_0.126[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-108 Lead Regi Adjustment
(Duplex/Heavyweight1/63[mm/s])
40 0 80 Sub Scanning Direction Regi Adjustment (Duplex/Heavyweight1/63[mm/s])_0.126[mm/step] Adjust-
ment
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
742-109 Lead Regi Adjustment
(UI Adjustment ValueMSI)
0 -4 4 Sub Scanning Direction from the UI Regi Adjustment (MSI)_0.504[mm/step] Adjustment (=0.126mm/
stepX4step)
*Adjusting the value in the plus (+) direction makes the lead edge margin wider.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
