6.3.6 NVM 742_Paper Handling List
Version 1.1
General
742-142 Loop Amount Adjustment
(Tray 1/126[mm/s]/Plain);
("Regi Snr On Detection"~"Tray1 Feed
CL Stop")
0 -125 125 Adjusts the timing of when the Tray1 Feed CL should stop after the Regi Snr ON (Tray1/126[mm/s]/
Plain)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Tray1 Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OX
742-143 Loop Amount Adjustment
(Tray 2/126[mm/s]/Plain)
("Regi Snr On Detection"~"TM Regi
Stop")
0 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/126[mm/s]/Plain)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-144 Loop Amount Adjustment
(Tray 2/126[mm/s]/Extra Heavyweight)
("Regi Snr On Detection"~"TM Regi
Stop")
-21 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/126[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-145 Loop Amount Adjustment
(Tray 2/63[mm/s]/Extra Heavyweight)
("Regi Snr On Detection"~TM Regi
Stop")
-21 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/63[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-146 Loop Amount Adjustment
(Tray 2/63[mm/s]/Extra Heavyweight)
("Regi Snr On Detection"~"TM Regi
Stop")
-32 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/63[mm/s]/Extra
Heavyweight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-147 Loop Amount Adjustment
(Tray 2/126[mm/s]/HW Labels)
("Regi Snr On Detection"~"TM Regi
Stop")
-24 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/126[mm/s]/Labels)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-148 Loop Amount Adjustment
(Tray 2/63[mm/s]/HW Labels)
("Regi Snr On Detection"~"TM Regi
Stop")
-24 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/63[mm/s]/Labels)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-149 Loop Amount Adjustment
(Tray 2/63[mm/s]/HW Labels)
("Regi Snr On Detection"~"TM Regi
Stop")
-24 -125 125 Adjusts the timing of when the TM Regi should stop after the Regi Snr ON (Tray2/63[mm/s]/Labels2)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the TM Regi Stop (HotLine) ON timing.
+/-125ms Adjustment possible as 0 = 138.
OX
742-150 Loop Amount Adjustment
(MSI/126[mm/s]/Plain)
("Regi Snr On detection"~"MSI Feed
CL Stop")
-16 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (Tray1/126[mm/s]/Plain)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Tray1 Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OX
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
