Fuji Xerox DocuCentre SC2020 Service Manual

05/2014
6-47
DC SC2020
General
6.3.6 NVM 742_Paper Handling List
Version 1.1
742-151 Loop Amount Adjustment
(MSI/126[mm/s]/Heavyweight)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (MSI/126[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OX
742-152 Loop Amount Adjustment
(MSI/63[mm/s]/Heavyweight)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (Tray1/63[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 314.
OX
742-153 Loop Amount Adjustment
(MSI/63[mm/s]/Extra Heavyweight)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (Tray1/63[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 314.
OX
742-154 Loop Amount Adjustment
(MSI/126[mm/s]/Labels)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (MSI/126[mm/s]/Labels)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OX
742-155 Loop Amount Adjustment
(MSI/63[mm/s]/Labels)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (MSI/63[mm/s]/Labels)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 314.
OX
742-156 Loop Amount Adjustment
(MSI/63[mm/s]/HW Labels)
("Regi Snr On detection"~"MSI Feed
CL Stop")
0 -125 125 Adjusts the timing of when the MSI Feed CL should stop after the Regi Snr ON (MSI/63[mm/s]/Labels2)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OX
742-157 Loop Amount Adjustment
(Duplex/126[mm/s]/Plain);
("Regi Snr On Detection"~"Dup CL
Stop")
-16 -125 125 Adjusts the timing of when the Duplex CL should stop after the Regi Snr ON (Duplex/126[mm/s]/Plain)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Duplex Clutch OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OO
742-158 Loop Amount Adjustment
(Duplex/126[mm/s]/Heavyweight);
("Regi Snr On Detection"~"Dup CL
Stop")
-48 -125 125 Adjusts the timing of when the Duplex CL should stop after the Regi Snr ON (Duplex/126[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Duplex Clutch OFF timing.
+/-125ms Adjustment possible as 0 = 157.
OO
742-159 Loop Amount Adjustment
(Duplex/63[mm/s]/Heavyweight);
("Regi Snr On Detection"~"Dup CL
Stop")
-96 -125 125 Adjusts the timing of when the Duplex CL should stop after the Regi Snr ON (Duplex/63[mm/s]/Heavy-
weight)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Duplex Clutch OFF timing.
+/-125ms Adjustment possible as 0 = 314.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
