6.3.6 NVM 742_Paper Handling List
Version 1.1
General
742-160 Loop Amount Adjustment
(Invert/126[mm/s]/Plain)
("Regi Snr On Detection"~"Invert Motor
Stop")
0 -125 125 Adjusts the timing of when the Invert Motor should stop after the Regi Snr ON (Invert/126[mm/s]/Plain)
*Only engage in single sheet feed mode.
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Invert Motor Stop timing.
+/-125ms Adjustment possible as 0 = 137.
OO
742-161 Loop Amount Adjustment
(Invert/126[mm/s]/Heavyweight1)
("Regi Snr On Detection"~"Invert Motor
Stop")
0 -125 125 Adjusts the timing of when the Invert Motor should stop after the Regi Snr ON (Invert/126[mm/s]/
Heavyweight1)
*Only engage in single sheet feed mode.
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Invert Motor Stop timing.
+/-125ms Adjustment possible as 0 = 137.
OO
742-162 Loop Amount Adjustment
(Invert/63[mm/s]/Heavyweight1)
("Regi Snr On Detection"~"Invert Motor
Stop")
0 -125 125 Adjusts the timing of when the Invert Motor should stop after the Regi Snr ON (Invert/63[mm/s]/
Heavyweight1)
*Only engage in single sheet feed mode.
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the Invert Motor Stop timing.
+/-125ms Adjustment possible as 0 = 306.
OO
742-163 Regi Assist Start Timing Adjustment
(Tray1/MSI/Tray2 Common)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (Tray1/MSI/Common Tray2)
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-164 Regi Assist Start Timing Adjustment
(MSI)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (MSI)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-165 Regi Assist Start Timing Adjustment
(Tray2)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (Tray2)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-166 Regi Assist Start Timing Adjustment
(1G)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (1G)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-167 Regi Assist Start Timing Adjustment
(2G)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (2G)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-168 Regi Assist Start Timing Adjustment
(3G)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (3G)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-169 Regi Assist Start Timing Adjustment
(4G)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (4G)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-170 Regi Assist Start Timing Adjustment
(Tray 1/126[mm/s]/Plain);
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (Tray1/126[mm/s]/Plain)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-171 Regi Assist Start Timing Adjustment
(MSI/126[mm/s]/Plain)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (MSI/126[mm/s]/Plain)_1[mm/step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-172 Regi Assist Start Timing Adjustment
(MSI/63[mm/s]/Heavyweight)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (MSI/63[mm/s]/Heavyweight)_1[mm/
step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
742-173 Regi Assist Start Timing Adjustment
(MSI/126[mm/s]/Heavyweight)
0 -127 127 Adjusts the Assist Operation start timing when Regi is ejected (MSI/126[mm/s]/Heavyweight)_1[mm/
step]
**Adjusting the value in the plus (+) direction delays the Assist Operation Start timing.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
