05/2014
6-51
DC SC2020
General
6.3.6 NVM 742_Paper Handling List
Version 1.1
742-204 Regi Assist Stop Timing Adjustment
(MSI/63[mm/s]/Labels2)
0 0 961 Adjusts the timing of when the MSI Feed CL should stop after the Regi Feed starts (MSI/126[mm/s]/
Labels2)
Adjusts by 1[ms/step].
*Adjusting the value in the plus (+) direction delays the MSI Feed CLL OFF timing.
OO
742-205 Registration Operation Stop Timing
(63[mm/s])
(Regi Snr Off)(RT4)
0 0 100 Regi CL Stop Timing Adjustment (63[mm/s])_1[ms/step] Adjustment
+/-100ms Adjustment possible as 0 = 165.
OO
742-206 Registration Operation Stop Timing
(126[mm/s])
(Regi Snr Off)(RT4)
0 0 100 Regi CL Stop Timing Adjustment (126[mm/s])_1[ms/step] Adjustment
+/-100ms Adjustment possible as 0 = 83.
OO
742-207 Invert Motor Current Value Weak Cur-
rent
2 0 15 Invert Motor Weak Current Value
0.1[A] Adjustment
OO
742-208 Invert Motor Current Value Mid-current
(63[mm/s])
4 0 15 Invert Motor Mid-current Value (63[mm/s])
0.1[A] Adjustment
OO
742-209 Invert Motor Current Value Weak Cur-
rent (126[mm/s])
4 0 15 Invert Motor Weak Current Value (126[mm/s])
0.1[A] Adjustment
OO
742-210 CW->CCW Switch Timing (126[mm/s]/
Plain)(IT3)
-48 -100 100 Adjusts the timing of when the Invert Motor forward rotation should stop for the purpose of paper inver-
sion after the paper transport Exit Sensor 1 Off (126[mm/s]/Plain)_1[ms/step]
+/-100ms Adjustment possible as 0 = 321.
OO
742-211 CW->CCW Switch Timing (63[mm/s]/
Heavyweight1)(IT3)
-87 -200 200 Adjusts the timing of when the Invert Motor forward rotation should stop for the purpose of paper inver-
sion after the paper transport Exit Sensor 1 Off (126[mm/s]/Heavyweight1)_1[ms/step]
+/-200ms Adjustment possible as 0 = 672.
OO
742-212 CW->CCW Switch Timing (126[mm/s]/
Heavyweight1)(IT3)
-53 -100 100 Adjusts the timing of when the Invert Motor forward rotation should stop for the purpose of paper inver-
sion after the paper transport Exit Sensor 1 Off (126[mm/s]/Heavyweight1)_1[ms/step]
+/-100ms Adjustment possible as 0 = 321.
OO
742-213 CCW->CW Switch Timing (Case 1)
(126[mm/s]/Plain)(IT1)
0 -100 100 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Regi Start (126[mm/s]/Plain)_1[ms/step]
+/-100ms Adjustment possible as 0 = 242.
OO
742-214 CCW->CW Switch Timing (Case 1)
(63[mm/s]/Heavyweight1)(IT1)
0 -200 200 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Regi Start (63[mm/s]/Heavyweight1)_1[ms/step]
+/-200ms Adjustment possible as 0 = 681.
OO
742-215 CCW->CW Switch Timing (Case 1)
(126[mm/s]/Heavyweight1)(IT1)
0 -100 100 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Regi Start (126[mm/s]/Heavyweight1)_1[ms/step]
+/-100ms Adjustment possible as 0 = 242.
OO
742-216 CCW->CW Switch Timing (Case 2)
(126[mm/s]/Plain)(IT1)
0 -100 100 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Exit Snr ON (126[mm/s]/Plain)_1[ms/step]
+/-100ms Adjustment possible as 0 = 242.
OO
742-217 CCW->CW Switch Timing (Case 2)
(63[mm/s]/Heavyweight1)(IT1)
0 -200 200 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Exit Snr ON (63[mm/s]/Heavyweight1)_1[ms/step]
+/-200ms Adjustment possible as 0 = 681.
OO
742-218 CCW->CW Switch Timing (Case 2)
(126[mm/s]/Heavyweight1)(IT1)
0 -100 100 Adjusts the timing of when the Invert Motor reverse rotation should stop for the purpose of paper inver-
sion after the Side2 Exit Snr ON (126[mm/s]/Heavyweight1)_1[ms/step]
+/-100ms Adjustment possible as 0 = 242.
OO
Table 1 NVM 742_Paper Handling List
Chain-Link NVM Name
Default
Value
Minimum
value
Maximum
value Description
Write
Allowed/
Protected
Can be
initialized
To Next Page
