05/2014
6-186
DC SC2020
6.3.22 System_Data (FAX Service)
Version 1.1
General
825-032 Redial Attempt Making the outgoing call again for no. of this system data shall
be decided by the following requirements.
[When Busy Tone Detection[Prohibited]]
· End when destination does not answer
[When Busy Tone Detection[Allowed]]
· End by Busy Tone Detection
O 3 0~9: 0time~9times
825-033 Maximum No. of Redial 14 0~255: 0time~255times
825-034 Redial Interval O 1 1~15: 1min~15min
825-035 FAX Communication Interval Interval time for independent communication interval. Always
wait for this system data time between outgoing call and out-
going call.
O 8 3~255: 3s~255s
1STEP/1S
825-036 Same Destination Check for Re-Outgoing Call 10: OFF
1: ON
825-037 Interval time to same destination 60 1~255: 1s~255s
825-045 RingThreshold This is the setting of DAA Register 730. 0xE8 0x00~0xFF
825-046 Complex This is the setting of DAA Register 731. 0x02 0x00~0x02
825-047 DCCurve This is the setting of SiDAA Register 733. 0x02 0x00~0x04
825-048 Rmake This is the setting of SiDAA Register 734. 0x01 0x00~0xFF
825-049 FastEdgePulseDial This is the setting of SiDAA Register 74F. 0x01 0x00~0x01
825-050 SiDAA Operation Mode By [OR] each Bit in this system data, you can decide the sys-
tem data usage of setting value by country.
0x01:Reserve
0x02:Reserve
0x04:Decide whether to detect RING when Line Monitor is
ON.
0x08:Reserve
0x10:Reserve
0x20:Reserve
0x40:Reserve
0x80:Reserve
0x00 0x00~0xFF
0x01: Reserve
0x02: Reserve
0x04: RING check with line monitor
ON
0x08:Reserve
0x10: Reserve
0x20: Reserve
0x40: Reserve
0x80: Reserve
825-054 Off HOOK Threshold Value Selection Selecting External Telephone HOOK Detection Threshold
Value
O 1 0: Low
1: Medium
2: High
825-060 DM Prevention Function O 0 0: Prohibit
1: Allowed
825-062 No. of Dial Pulse Select No. of DP Pulse 0 0: N
1: 10-N
2: N+1
825-063 PB Output Time PB (DTMF) Signal Sending Time 100 0~255: 0ms~255ms
1STEP/1ms
825-064 PB Pause Time PB Minimum pause time 120 0~255: 0ms~255ms
1STEP/1ms
825-065 DTMF Sending Attenuator Level DTMF Sending Level Setting 6 4~15: -4dbm~-15dBm
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
