Fuji Xerox DocuCentre SC2020

05/2014
6-187
DC SC2020
General
6.3.22 System_Data (FAX Service)
Version 1.1
825-066 DTMF Highh/Low Frequency Level Difference High frequency, Low frequency level difference setting for PB
(DTMF) Dial.
Level Difference: High frequency/Low frequency
0 0: 0dB
1: 2.5dB
2: 3.0dB
3: 3.5dB
4: 4.0dB
5: 4.5dB
6: 5.0dB
12: 0dB
13: 0.5dB
14: 1.0dB
15: 1.5dB
825-067 10PPS Make TIme 31 1~106: 1ms~106ms
1STEP/1ms
825-068 10PPS Break Time 67 1~106: 1ms~106ms
1STEP/1ms
825-069 10PPS Make TIme 16 1~106: 1ms~106ms
1STEP/1ms
825-070 10PPS Break Time 34 1~106: 1ms~106ms
1STEP/1ms
825-071 DP Inter Digit Pause Time 36 0~255: 0ms~5110ms
1STEP/20ms
825-072 (4/0.1) Pause Time This is the Pause Down Time. When dialing Pause[-], dial the
next next dial data after waiting for the system data time.
40 0~255: 0ms~25500ms
1STEP/100ms
825-073 Blind Dial Time Time to start dialing after line closed when connecting to PBX
(1.3secs will be added to the setting value from the Modem
Restriction)
3 3~255: 3s~255s
-- Apply the following setting range
only for South Africa setting
1~255: 1s~255s
825-074 Dial Tone Detection Timeout Time This will be used as Timeout when Dial Tone cannot be
detected.
20 0~255: 0s~255s
1STEP/1S
825-079 ONHOOK Detection Time This is the time it takes to determine the external telephone is
ONHOOK.
65 10~255: 200ms~5100ms
1STEP/20ms
825-080 OFFHOOK Detection Time when there is no
RING signal in line
This is the time it takes to determine the external telephone is
OFFHOOK when there is no RING signal coming in.
15 15~255s: 300ms~5100ms
1STEP/20ms
825-081 OFFHOOK Detection time when there is RING
signal in the line.
This is the time it takes to determine the external telephone is
OFFHOOK when there is RING signal coming in.
15 15~255ms 300ms~5100ms
1STEP/20ms
825-083 Ring Volume Setting O 3 0: Mute
1: Soft
2: Normal
3: Loud
825-084 External Telephone Call frequency ON 1step/0.5 micro-s 62500 6250~65535: 3125 micro-s~31250
micro-s
825-085 External Telephone Call frequency OFF 1step/0.5 micro-s 62500 6250~65535: 3125 micro-s~31250
micro-s
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
