05/2014
6-188
DC SC2020
6.3.22 System_Data (FAX Service)
Version 1.1
General
825-086 External Telephone Call ON TimeT1 Rumbling Pattern during quasi-RING Back tone/External
Speaker Rumbling ON Time1
50 5~250: 100ms~5000ms
1STEP/20ms
825-087 External telephone call OFF Time T2 Rumbling Pattern during quasi-RING Back tone/External
Speaker Rumbling OFF Time1
100 5~250: 100ms~5000ms
1STEP/20ms
825-088 External Telephone Call ON TimeT3 Rumbling Pattern during quasi-RING Back tone/External
Speaker Rumbling ON Time2
50 5~250: 100ms~5000ms
1STEP/20ms
825-089 External telephone call ON Time T4 Rumbling Pattern during quasi-RING Back tone/External
Speaker Rumbling OFF Time2
100 5~250: 100ms~5000ms
1STEP/20ms
825-090 Detect Dial Tone in Public Line Dial Tone Detection Setting during PSTN connection 1 0: Detect
1: Do not Detect
825-092 CED Signal Sending Start Time when manual
receiving
1STEP/100ms 0 0~255: 0ms~25500ms
825-093 CNG Signal Sending Start Time 1STEP/100ms 30 0~255: 0ms~25500ms
825-094 CNG Sending Start Time when manual sending 1STEP/100ms 0 0~255: 0ms~25500ms
825-096 Remote Receiving O0 0: OFF
1: ON
825-097 Remote Receiving DTMF No.1 O0 0~9
825-098 Remote Receiving DTMF No.2 O0 0~9
825-099 Ring ON Decision Time 155 0~255 1step/1ms
825-100 Ring OFF Decision Time 120 0~255 1step/10ms
825-101 Time to determine the Ring has disappeared
from line
55 0~255 1step/100ms
825-102 PrefixDial O 0 0: Do not attach
1: Attach
825-103 PrefixDial Number1 O 0 NULL,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’,’0’,’#’,
’*’
825-104 PrefixDial Number2 O 0 NULL,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’,’0’,’#’,
’*’
825-105 PrefixDial Number3 O 0 NULL,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’,’0’,’#’,
’*’
825-106 PrefixDial Number4 O 0 NULL,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’,’0’,’#’,
’*’
825-107 PrefixDial Number5 O 0 NULL,’1’,’2’,’3’,’4’,’5’,’6’,’7’,’8’,’9’,’0’,’#’,
’*’
825-108 SiDAA Manual Calibration 00: OFF
1: ON
825-110 Dial Tone Pattern Detection 0 0: Do not detect Pattern (detect with
more than continuous 800ms
1: Detect Pattern
825-111 Dial Tone ON/OFF Time Lower Limit 10 8~255 1step/10ms
825-112 Dial Tone ON/OFF Time Upper Limit 100 8~255 1step/10ms
825-201 NCU Country Relay Setting Add for South Africa/Mexico Testing. 0 0: Disabled
1: Enabled
Table 1 6.3.22 System_Data (FAX Service)
Chain-Link NVM Name Detailed Description OFF/ON Default Value Setting Range
To Next Page
