6.3.22 System_Data (FAX Service)
Version 1.1
825-202 FastEdgePulseDial2 This is the setting of DAA Register 732. 0x00 0x00~0x02
825-203 DAA SSD Register 0x02 Setting 0xFD 0x00~0xFF
825-601 Line Monitor Setting O1 0: OFF
1: ON
825-602 Line Monitor Volume O 2 0: Mute
1: Soft
2: Normal
3: Loud
825-604 CED Detection Time 1STEP/20ms 25 25~255:
825-666 Manual Sending CNG Sending 10: Off
1: On
825-605 Select CNG Sending Stop Determination 0 0,1,2
0: CED & V.21 Preamble Detection
1: CED Detection
2: V21 Preamble Detection
825-608 RTN Command Sending Reference (Ratio) 1STEP/1% 5 0~100: 0%~100%
825-609 RTN Command Sending Reference (No. of
continuous line)
1STEP/1line 5 0~255: 0line~255line
825-610 T1 Timer Value immediately after outgoing call 1STEP/1S 50 0~255: 0s~255s
825-611 T1 Timer Value when sending 1STEP/1S 36 0~255: 0s~255s
825-612 T1 Timer Value when receiving 1STEP/1S 39 0~255: 0s~255s
825-613 T2 Timer Value 1STEP/100ms 60 0~255: 0s~25.5s
825-614 T3 Timer Value 1STEP/100ms 150 0~255: 0s~25.5s
825-615 Auto Sending/receiving T4 Timer Value 1STEP/100ms 30 0~255: 0s~25.5s
825-616 Manual Sending/receiving T4 Timer Value 1STEP/100ms 45 0~255: 0s~25.5s
825-617 Silent Time Timer Value 1STEP/1ms 75 0~255: 0ms~255ms
825-618 FSK Monitoring Timer Value 1STEP/1ms 200 0~255: 0ms~255ms
825-619 Image Information Sending Delay Time 1STEP/10ms 50 0~255: 0ms~2500ms
825-620 Image Information receiving Drop Out Monitor-
ing Timer Value
1STEP/10ms 100 0~255: 0ms~2500ms
825-621 NSF · DIS Sending Time 0 0: 3sec
1: 3.45sec
2: 2.55sec
3: 4.5sec
Table 1 6.3.22 System_Data (FAX Service)
